Specifications

With 3 shots per day, no recharging is needed for about 3 years.
Designed for repeated recharging and use.

* Charging must be performed in a non-hazardous (safe) area only.

Product name	LC-EX10 LTE
Dimensions	W130.2 × H156.0 × D26.1 mm (body only) W130.2 × H159.9 × D29.3 mm (including lens adapter)
Body Weight	Approx. 530 g
Communication (uplink)	LTE Cat.1
Certificate for potentially explosive atmospheres	IECEx, ATEX, Type Examination certificate in Japan (JPEx)
Performance for potentially explosive atmospheres	Intrinsically safe type of protection Ex ic IIC T6 Gc Ex ic IIIC T85°C Dc -20°C ≤ Tamb ≤ +60°C
Water/Dust Protection	IP65
Camera	CMOS image sensor (effective resolution 2560 × 1920)
Ratings	Battery powered, Um = 12.0 V
Operating temperature range	−20 °C to 60 °C
Operating humidity range	20% to 80%

Note:
For the initial camera setup, a dedicated iOS app is required.
Supports iOS 15 or later (as of July 2024).

Specific Conditions of Use
The following conditions relate to safe installation and/or use of the equipment.

i. Under certain extreme circumstances, the non-metallic parts incorporated in the enclosure of this equipment may generate an ignition-capable level of electrostatic charge. Therefore, the equipment shall not be installed in a location where the external conditions are conducive to the build-up of electrostatic charge on such surfaces. In addition, the equipment shall only be cleaned with a damp cloth.

ii. The equipment shall only be charged in the safe area.

iii. The equipment shall only be charged from a supply with a maximum output voltage of 12.0V and which complies with one of the following:
• is a SELV or PELV system.
• a safety isolating transformer complying with the requirements of IEC 61558-2-6 or technically equivalent standard.
• apparatus complying with the IEC60950 series, IEC61010-1, or a technically equivalent standard.
• fed directly from cells or batteries.
